An arch frame head is secured using two clips from the T500SW series system. Each mounting clip is fastened with four PH.12xa.P screws, measuring 2 inches long. Additional fasteners secure the structural components at the head junction.
06 PH.12xa.P 4 PER CLIP PH.12xa.P 4 PER CLIP OPG1999 2" LONG OPG1999 2" LONG OPGRAFT Arch Ref: SYSTEM: AT HEAD CLIP DETAIL 2a N/A T500SW SERIES
