A gusset plate connects diagonal structural steel bracing members to a horizontal structural steel beam. The gusset plate features half-inch thick stiffeners on both sides and is bolted to the brace members. Welds secure the gusset plate to the beam flange with specific sizing parameters indicated for the z-region. A work point is located at half the actual beam depth. Additional stiffeners and weld sizes are specified per the accompanying notes.
2 SIDES TYP X X z W b 6 SEE z W bz IN "Z" REGION (TYP) 9 SEE BEAM W.P. @ 1/2 ACTUAL BM DEPTH 7 z GUSSET STIFFENER, 12 " STIFF BOTH SIDES OF GUSSET, SEE 5 4 L gc APPROX 90° SEE NOTE A FOR SIZE L gb TYP. APPROX 2*(L wb -z)
