C-RWPA2 — Utility Gate Detail

Civil · C-RWPA2

Utility Gate Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: C5
Discipline: Civil

Materials

Brick Masonry / CMU Metal (misc.)

Elements

Anchors / Embeds Entrances Facades / Cladding Walls Waterproofing / Flashing

Connections

Base Plate / Anchorage

Text on the drawing

CMU BLOCK BRICK VENEER. METAL GATE; RE: B5/U-601 1" AIR SPACE BACKER ROD & SEALANT GATE HINGE 6" 2 1/2" EXPANSION ANCHOR 6"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
