Civil · C-RCGRX

Light Duty Concrete Pavement Section

Materials

Elements

About this detail

This light duty concrete pavement section consists of a 5-inch Portland cement concrete wearing course with a 4,000 psi compressive strength at 28 days, 6 percent air entrainment, and a 4-inch slump. The concrete slab rests directly upon a 12-inch untreated base course compacted per the project geotechnical report and specifications. Below the base course sits a properly prepared subgrade or structural fill compacted to a minimum of 95 percent of maximum dry density determined by AASHTO T-180 method in lifts not exceeding 8 inches in loose thickness. All paving requires the removal of surface vegetation and deleterious materials over the entire site prior to placement.
