The tactile warning surface features a grid of truncated domes with a height of zero point two inches and a base diameter of zero point nine zero to zero point nine two inches. The spacing between dome centers measures zero point four five to zero point four seven inches, with overall pad dimensions sized per plan. Detail B indicates a dome center-to-center spacing of two point three to two point four inches in both orthogonal directions.
PER PLAN 2.3" - 2.4" 2.3" - 2.4" 0.45" - 0.47" 0.90" - 0.92" PLAN VIEW DETAIL B TRUNCATED DOME PER PLAN 01 B -- 0.2"
