The door jamb frames a partition built with metal studs and layered gypsum board panels on the pull and push sides. A rabbet of variable depth receives the door frame profile, secured against the partition edge. The partition thickness and soffit dimensions are sized per schedule.
PER SCHEDULE PARTITION REQUIRED RABBET AS AS REQUIRED SOFFIT 2" 5/8" 1/2" 1" PUSH SIDE PULL SIDE VARIES
