A concrete curb and gutter profile features an eighteen-inch total width with specific radii and slope dimensions. A one-half-inch radius is detailed at the top back and flow line, alongside a one-inch radius at the gutter transition. Number four by twelve-inch slip dowels with a one-quarter-inch expansion joint material are spaced at twenty feet on center. The subgrade preparation requires review of the geotechnical report, and adjacent pavement or base sections are sized per plan.
