The assembly details utility connection sizes and locations for a Market Forge 30-STGM tilt skillet. Faucet water supply lines are designated with specific dimensional coordinates and heights. An electrical conduit connection feeds the unit at the specified voltage and phase. Drain and service pipe sizing is called out adjacent to the equipment footprint.
23 3/8 60 FOR FAUCET 22 3/8 60 FOR FAUCET C57 21 TILT. SKILLET MARKET FORGE 30-STGM 12 208 3 33.3 50 STD 2 8 3/4 84 CONDUIT CONNECTION 26 28 27
