C-PKV9R — Typical Metal Deck Opening At Roof Details

Civil · C-PKV9R

Typical Metal Deck Opening At Roof Details

Units: imperial
Sheet: C6X
Discipline: Civil

Materials

Metal (misc.)Steel

Elements

Beams Decks Roof / Floor Openings Roofs

Connections

Beam-to-Beam Welded Connection

Text on the drawing

STEEL BEAM PER PLAN L6x4x5/16x0'-4"(LLV) (CENTERED ON C6) STEEL BEAM PER PLAN C6x8.2 C4x5.4 C6x8.2 * OPENING C4x5.4 TYP STEEL BEAM PER PLAN TYP C6x C4x DETAIL 3'-0" x 3'-0" MAXIMUM OPENING DETAIL 10'-0" MAX B A A B TYP 3" MAX 1/4 2-12 3 SIDES 3/16 3/16

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
