A PVC pipe and cross are secured to a flow control structure using a three-eighths-inch deformed steel rod or aluminum rod cut to length. The rod is anchored back to the structure using a cinch anchor and fastened with stainless steel wire rope clips. The assembly provides secure lateral restraint for piping components within civil drainage and utility structures.
FLOW CONTROL STRUCTURE 3VC 3I3E CROSS 'EFOR0E' STEEL RO' SS OR ALU 0INU0 LENGTH TO FIT WIRE RO 3E CLI3 SS CINCH ANCHOR DETAIL A: PIPE SUPPORT DETAIL
