Standard and van accessible parking signs, designated as Sign No. R7-8 and Sign No. R7-8P, feature layouts and dimensions including an eighteen inch height by twelve inch width with a one and a half inch corner radius and specific vertical spacing dimensions for text and symbol elements. Notes specify a white retroreflective background with green retroreflective legends, and a white on blue retroreflective symbol for standard signs.
