C-NR34G — Erosion and Sediment Control Details

Civil · C-NR34G

Erosion and Sediment Control Details

About this detail

Erosion and sediment control details for civil site preparation including silt fences with fiber rolls, stabilized construction entrances, and on-site and off-site inlet protection. The details show continuous fiber rolls with 24-inch minimum overlap, temporary sidewalks, chain link fences, water-filled barriers, wood stakes spaced at 3 feet on center, and filter fabric placement around drop inlets. Accompanying notes specify installation procedures, staking requirements, maintenance guidelines, and sediment removal practices.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
