The detail indicates a stud top diameter ranging from 0.45 inches minimum to 0.47 inches maximum, and a base diameter ranging from 0.9 inches minimum to 0.92 inches maximum. The height is 0.2 inches. Center-to-center spacing for the stud array is specified as 2.3 inches minimum and 2.4 inches maximum.
0.45" MIN AND 0.47" MAX TOP DIA 0.9" MIN AND 0.92" MAX BASE DIA 2.3" MIN AND 2.4" MAX CENTER TO CENTER SPACING 2.3" MIN AND 2.4" MAX CENTER TO CENTER SPACING 0.2"
