This dual-faced concrete curb features a total height of 1 foot 4 inches and a top width of 6 inches, expanding to a base width of 9.5 inches. The curb profile includes 1-inch radii at both top edges. The curb face height is 6 inches above the adjacent landscaping or paving, which is to be determined per the site plans. The overall width at the top including the face offsets is 8 inches.
