A 2 inch by 3 inch by 3/16 inch galvanized and painted steel tube serves as the sign post, with its top end capped. The post extends down into a concrete footing below the finish grade and pavement. A 12 inch by 24 inch reflectorized sign with a white wheelchair symbol and fine text is mounted above a van accessible supplementary sign. Sign colors feature a white retroreflective background with a black border and legend.
CONCRETE FOOTING FINISH GRADE/PAVEMENT 2" X 3" X 3/16" GALV. STEEL TUBE AND PAINTED, CAP TUBE END. VAN ACCESSIBLE SIGN WITH WHITE BEADED TEXT OR EQUAL ON BLUE BACKGROUND. WHERE OCCURS. 12" X 24 REFLECTORIZED SIGN. WHEEL CHAIR SHALL BE WHITE ON BLUE BACKGROUND WITH "MINIMUM FINE $250" 1'-0" 4" 1'-8" 6" 2'-6" 6'-8" 1'-0" EQ. FOR ALL STALL SIGNS 2'-0" 7" 1'-5" COLORS: BORDER & LEGEND - BLACK BACKGROUND - WHITE (RETROREFLECTIVE)
