An exterior concrete stairway connects to an adjacent concrete sidewalk and slab on grade outside an industrial building wall. A six-inch scum piping blind flange is set into the grade near the foundation. The stair features steel stringers and railings rising alongside a precast concrete wall panel.
SLAB ON GRADE (D2 STAIRWAY (D1 i JljW j i i ■ - *, -■ b D4 6" SCUM PIPING BLIND FLANGE, PIP ------------------- CONCRETE SIDEWALK ( d 3^
