A rigid pavement fillet assembly with a minimum three-foot radius features the intersection of construction or contraction joints alongside doweled contraction joints within the slab. The layout governs joint placement and transition geometry at pavement fillets.
FILLET R. OF FILLET CONSTRUCTION OR CONTRACTION JOINT DOWELED CONTRACTION JOINT 3'-0" MIN
