A standard French drain assembly is set within native material excavation and finished grade. A perforated pipe of a size determined per plans is bedded on a minimum of one inch of sand or rock at the trench bottom, surrounded by three-quarter inch clean crushed rock with a minimum twelve-inch depth above the pipe crown. A geotextile filter fabric, specified as Mirafi 140N or an approved equal, completely wraps the crushed rock bed beneath four inches of sand and surface material per the landscape plan, maintaining minimum six-inch side clearances. A secondary detail shows a black NDS atrium grate connected via a six-inch PVC riser and wye fitting to the storm pipe run, with the grate rim installed flush with finish grade or wood mulch unless noted otherwise.
FRENCH DRAIN NTS FINISH GRADE NATIVE MATERIAL PERFORATED PIPE (SIZE PER PLANS) 01 01 02 03 3/4" CLEAN CRUSHED ROCK 04 GEOTEXTILE FILTER FABRIC (MIRAFI 140N OR APPROVED EQUAL) 05 02 05 4" MIN. VARIES 12" MIN. 1" MIN. PIPE SIZE PER PLANS PIPE SIZE PER PLANS 6" MIN. 6" MIN. 06 06 MATERIAL PER LANDSCAPE PLAN 07 SAND 07 04 03 NOTE: UTILITY TRENCH BACKFILL IS EXEMPT FROM SPECIAL INSPECTION AND TESTING. 06 1 2 3 4 5 ATRIUM GRATE BLACK NDS 6" PVC RISER WYE FITTING STORM PIPE AS SHOWN ON PLAN INVERT ELEVATION PER PLAN 6 PLUG IF AT END OF RUN 7 TOP OF GRATE (TG) ELEVATION PER PLAN 2 1 7 6 5 4 3 1 GRATE RIM FLUSH WITH FINISH GRADE UNLESS NOTED OTHERWISE 8 8 WOOD MULCH PER LANDSCAPE UNLESS NOTED OTHERWISE. 9 9
