Wall drainage conditions where gutters are not required, featuring an approximate flow line that transitions from a specified slope to a minimum ten percent slope toward a return wall. The limit of line and grading geometry provide positive surface drainage away from the wall structure.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
