This concrete curb and gutter assembly features a twelve-inch overall height and a twenty-four-inch total width, resting on a compacted select fill base. The profile includes a six-inch top width with three-quarter-inch radii at the transitions, and a contraction joint located toward the base. The curb and gutter installation complies with APWA standards plan number 205.
BOTTOM OF CONTRACTION JOINT (TYP.) 6” R=3/4” CM i^ CO o' :► 0 ►. ► A' ► 0 V V,\\V; V SELECT FILL (TYP.) \ \ \ / >\ •/ / NOTE: CURB AND GUTTER TO BE INSTALLED PER APWA STANDARDS PLAN NO. 205 24”
