A preformed compression seal is installed within a construction joint in Portland cement concrete pavement with the top of the seal positioned six below the pavement surface. The joint faces are lubricated as specified, and the joint is centered on the initial sawcut at a width ranging from six to thirteen per manufacturer specifications.
PREFORMED COMPRESSION SEAL LUBRICATE AS SPECIFIED PCC PAVEMENT TOP OF SEAL 6 BELOW PAVEMENT PER MANUF. SPECIFICATIONS CONSTRUCTION JOINT 6 TO 13 CENTER ON INITIAL SAWCUT JOINT SEAL
