This structural detail shows a sixteen-inch cast-in-place concrete basement wall with a three-quarter-inch chamfer at the inside face. Hooked basement wall reinforcement is provided on each side of the chamfer, set three feet and three-quarters of an inch from the reference line. Formsavers are installed at the basement wall construction joint. Grid lines 11.6 and 12 establish the layout orientation.
12 11.6 3'-0 3/4" WALL 16" BSMT 16 S501 3/4" CHAMFER @ IF OF WALL; PROVIDE HOOKED HEF BSMT WALL REINF ON EACH SIDE OF CHAMFER 16" PROVIDE FORMSAVERS AT BMST WALL
