A painted traffic sign displays non-reflective white letters reading TOW ONLY centered within a non-reflective black rectangular border. The rectangular sign layout measures six hundred ten millimeters tall with three hundred millimeter spacing margins. Geometric location coordinates align the sign with the towway centerline marking. Dimension callouts indicate three hundred millimeter clearances and a one hundred fifty millimeter offset from the centerline.
TOW ONLY 610 300 300 610 300 GEOMETRIC LOCATION 150 TOWWAY CENTERLINE MARKING RE: D5/CT501 300 300 NON-REFLECTIVE WHITE LETTERS WITHIN A NON-REFLECTIVE BLACK RECTANGULAR BORDER
