A web doubler plate is welded to the structural steel column web with fillet welds or complete joint penetration groove welds executed per AWS D1.8 Clause 4.3. A stiffener plate is positioned at the beam connection with a three-sixteenths inch minimum edge weld size and extends four inches past the connection. A gusset plate connects to the assembly, with plate thicknesses proportioned relative to the doubler plate thickness, designated as t-doubler. Section A-A details the cross-sectional weld configuration and plate placement between the column flanges.
OR CJP WEB DOUBLER PLATE GROOVE WELD PER AWS D1.8 CLAUSE 4.3 t Dblr COLUMN A A SECTION A-A 1 14 *t Dblr 2" BEAM A A 3 4 *t Dblr 316 MIN WELD SIZE @ EDGE, TYP. 4" 2" STIFFENER PLATE 4 SEE 1 BEAM A 4" 2" WEB DOUBLER PLATE GUSSET o o L K / i* i* F 1 i 1 rE x o o
