Storm drain inlet protection measures are detailed for both sump and grade conditions using arrangements of sandbags and rock sacks. The inlet features either a filter fabric or basket positioned below the grate to capture sediment. Sandbags are stacked one bag high at the spillway and two bags high along the sides to direct non-storm water flow. Rock sacks or sandbags are placed along the edge of pavement to manage runoff velocity. General notes specify that these temporary measures are intended for short-term use, require proper maintenance and cleanup, and must be removed after adjacent construction operations are completed.
Storm Drain Inlet Protection SE-10 Inlet Edge of Pavement. L / Flow Flow (inlet to have filter fabric or basket' Spillway, 1—bag high 2 - b a g s Is i g h typical protection for inlet on sump Edge of Pavement Inlet Flow Flow (inlet to have filter fabric or basket) l^bags Rj Spillway, 1 bag high 2-hags high TYPICAL PROTECTION FOR INLET ON GRADE NOTES: 1 Intended for short-term use 2 Use to inhibit non-storm water flow 5 Allow for proper maintenance and cleanup 4 Bags must be removed after adjacent operation is completed 5 Not applicable in areas with high silts and clays without filter fabric. %■. the inlet is tlp^^a'frbifhipt^fttelcbtrfiWStegcSPpSiflJtSav.rces of pollution. June 2012 California Stormwater BMP Handbook Construction www.casqa.org 9 of 10
