A Type C compression seal joint occurs at transverse and longitudinal construction joints in continuously reinforced concrete pavement. A preformed compression seal is installed within a saw-cut joint of specified depth in the pavement surface. Dimensions indicate a nominal seal width ranging up to 1/2 inch with specific edge offsets.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
