A gusset plate connects a buckling-restrained brace to a steel column and beam intersection. The work point is located at the center of the column and half the actual beam depth. A beam shear tab with bolts connects the beam web to the column flange. Additional stiffener plates are located inside the column web aligned with the beam flanges.
L gc APPROX COL 4 L gb APPROX 6 SEE W b BEAM 90° 6 SEE W c W.P. @ CNTR OF COL & 1/2 ACTUAL BM DEPTH X X 7 4 1 L wc L wb 8 TYP SEE DETAILS 1 AND 2 FOR BRB & GUSSET LAYOUT PROCEDURE. A
