This concrete storm drain inlet structure features an H-20 traffic-rated thirty-inch by thirty-inch cast iron grate and frame set flush with final grade, providing a two-square-foot opening area. A removable filter basket hangs below the inlet opening above a pipe connection. The twelve-inch thick concrete walls are reinforced with number four bars spaced at nine inches and twelve inches each way, tied into a base slab with number four reinforcing mats. A two-inch by four-inch construction joint separates the base from the walls, and overall depth varies per profile.
8" 2'-0" MIN 4" 4'-0" MIN 6'-0" MAX 6" MIN #4 @ 12" E.W. #4 @ 9" E.W. 2" X 4" CONSTRUCTION JOINT #4 @ 12" (TYP) #4 @ 9" (TYP) FINAL GRADE H-20 TRAFFIC RATED 30"X30" GRATE AND FRAME FOR INLETS (2.00 sq. ft. OPENING AREA) 1'-0" VARIES (SEE PROFILES) 8" FILTER BASKET NOTE: 1. SEE PRECAST STRUCTURE NOTES ON CU502 IF SELECTING PRECAST INLETS VERSUS CAST IN PLACE. 12" WALL
