An accessible curb ramp Type B transitions from a sidewalk with a minimum width of five feet down to street level with a maximum slope of seven and a half percent. The ramp includes a curb transition and a patterned detectable warning surface that provides visual contrast with adjacent surfaces. General notes for this installation are cross-referenced with Type A curb ramp details on the same drawing sheet.
