An OPG1900 series head and jamb connection is secured with 1/4-20 Hilti Dril-Flex self-drilling screws placed two each side of the vertical T-clip and four at the F-clip per ICC-ESR 3332. The assembly incorporates components OPG1999, OPG1901, OPG1978, OPG1552, and OPG1910 to establish the frame dimension and daylight opening tolerances.
PH.12xa.P FH.12xa.S Arch Ref: SYSTEM: F-ANCHOR HEAD DETAIL AT JAMB A N/A OPG1900 SERIES 5 8" 33 4" 21 4" D.L.O. FRAME DIMENSION 3 4" 10 13 OPG1999 4 3/8" LONG OPG1901 OPG1978 OPG1552 4 11/16" LONG OPG1910 3" 1/4-20 HILTI DRIL-FLEX (2) EA. SIDE OF VERTICAL T-CLIP (4) AT F-CLIP @ JAMB PER [ICC-ESR 3332]
