An aluminum metal panel with a thickness of .125 inches connects to the jamb of an OPG1900 series system. The panel edge engages the framing profile with sealant joints referenced at the top and bottom. Fasteners secure the framing assembly adjacent to the wall opening.
G1 G1 Arch Ref: SYSTEM: AT METAL PANEL JAMB DETAIL 1a N/A OPG1900 SERIES .125" ALUM. METAL PANEL
