Non-Movement Area Boundary Marking

About this detail

Standard layout for non-movement area boundary markings adjacent to a taxiway centerline. The assembly consists of a twelve-inch yellow solid line on the non-movement side and a twelve-inch black dashed line with three-foot segments on the movement side, framed by six-inch black borders on both edges. Final markings are specified as thermoplastic while temporary markings are painted, with station and offset location callouts referenced to the taxiway centerline.
