An angle clip measuring two inches long is secured with four PH.12xa.P fasteners per clip to the OPG1999 component. The vertical leg of the clip attaches to the framing assembly using a threaded fastener. The connection forms part of the T500SW series system detail at the head condition.
PH.12xa.P 4 PER CLIP OPGRAFT OPG1999 2" LONG 06 Arch Ref: SYSTEM: AT HEAD CLIP DETAIL 3a 1/A8.16 SIM. T500SW SERIES
