This mountable concrete curb and gutter profile features a six-inch high back section, an eight-inch vertical rise with a quarter-inch top chamfer, and a twelve-inch sloping face at an eight to twelve batter. The overall assembly includes a six-inch high outer edge tapering down to a one-and-a-half-inch top width on the gutter side. All dimensions and geometry are detailed for civil site grading and roadway drainage.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
