C-9KMNV — Typical Cmu Wall Reinforcing Detail

Civil · C-9KMNV

Typical Cmu Wall Reinforcing Detail

Units: imperial
Sheet: C12
Discipline: Civil

Materials

Reinforced Concrete Masonry / CMU

Elements

Walls Reinforcing

Text on the drawing

CMU WALL PER PLAN / ELEVATION HORIZONTAL REINFORCEMENT PER WALL ELEVATION VERTICAL REINFORCEMENT PER WALL ELEVATION PER ELEVATION SPACING 8" CMU WALL - REBAR CENTERED

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
