This cross section details a precast concrete interceptor vault with internal baffle walls, inlet and outlet drop tees, and dual access risers. The outlet invert is set at fifty-seven inches, while inlet inverts range from seventy-three to seventy-five inches depending on the model. Vertical dimensions for the access risers span from thirteen to seventy-two inches based on the specific JZ-series unit selected. The structure features precast concrete walls, base slab, and top slab with integrated piping connections.
CROSS SECTION 72" (JZ-2000-EBE-G) 57" OUTLET INVERT 13" MIN TO 60" MAX (JZ-2500-EBE-G) 59" INLET INVERT 13" MIN TO 72" MAX (JZ-2000-EBE-G) 13" MIN TO 72" MAX (JZ-1500-EBE-G) 75" (JZ-1500-EBE-G) 73" (JZ-2500-EBE-G)
