An architectural head clip detail of the T500SW series utilizes an OPGRAFT framing profile secured with OPG1999 clips two inches long. Four PH.12xa.P fasteners connect each clip to the assembly. The vertical leg attaches with a flat head screw while the horizontal leg anchors into the overhead support.
PH.12xa.P 4 PER CLIP OPGRAFT OPG1999 2" LONG 06 Arch Ref: SYSTEM: AT HEAD CLIP DETAIL 1a 1/A8.16 SIM. T500SW SERIES
