A precast concrete gravity grease interceptor features internal piping with a four-inch inlet and outlet configuration. Access openings are topped with Neenah R-3493-A or East Jordan Iron Works 1771 frames and covers, set over adjustable grade rings as required by site conditions.
SECTION NEENAH R-3493-A OR EAST JORDAN IRON WORKS 1771 FRAME AND COVER OR APPROVED CONRTRACTOR TO PROVIDE GRADE RINGS AS REQUIRED 4" GRAVITY GREASE INTERCEPTOR EQUAL
