A pipe reducer is installed within a concrete trench, shown in typical profile, plan, and section views. Four reinforcing bars are positioned around the pipe profile with a typical twelve-inch dimension from the trench bottom and a six-inch side clearance. The plan view shows a twelve-inch dimension flanking the transition area, with a twenty-four-inch minimum vertical dimension indicated in the profile view.
12" REDUCER TRENCH BOTTOM 4 BARS TYPICAL PROFILE SECTION REDUCER PLAN 24" MIN VERT. 6" 12" 12" 3"
