Standard end connection configurations include stiffener and continuity plates at structural steel beams or columns. Continuity plates require a minimum thickness equal to the beam flange thickness plus one-eighth inch, welded with a fillet weld sized at five-eighths of the continuity plate thickness along three sides. Weld placement must maintain a one-and-a-half-inch minimum fillet weld holdback and be kept away from column k-areas. Bolt holes in connection lugs are standard holes.
PLAN VIEW 10 TYPICAL END CONNECTION DETAIL SCALE: NTS NOTE: BOLT HOLES IN CONNECTION LUGS ARE STANDARD HOLES. FOR CONTINUITY PLATE THICKNESS (t cont ) PROVIDE t fb + 18 " MINIMUM THICKNESS TYP, 3 SIDES, SEE STIFFENER PLATE: A AT CONT PL SEE AT MAIN PL SEE AT "z" REGION SEE A B B NOTES FOR SIZE NOTES: USE 5 8 t cont FILLET WELD SIZE STIFF/CONT PLATES AT BEAM OR COLUMN k 1 1 2 " MIN FILLET WELD HOLDBACK, TYP WELD PLACEMENT AWAY FROM k-AREAS 12 " MAX k-AREAS CL k 1
