A typical end connection for a buckling-restrained brace in a steel framing system features connection lugs with standard bolt holes as specified by project notes. Shaded regions designate protected zones encompassing the steel core and connection elements, satisfying the seismic requirements of Section F4.5c of AISC 341.
PROTECTED ZONES SHADED REGIONS INDICATE PROTECTED ZONES BRB PROTECTED ZONES SHALL INCLUDE THE STEEL CORE AND CONNECTION ELEMENTS AND SHALL SATISFY THE REQUIREMENTS OF SECTION F4.5c OF AISC 341. PLAN VIEW 5 TYPICAL END CONNECTION DETAIL SCALE: NTS NOTE: BOLT HOLES IN CONNECTION LUGS ARE STANDARD HOLES.
