Plan and elevation layout for truncated domes used as detectable warning surfaces. The square plate measures three feet by three feet with tapered edges where exposed. The domes feature a 0.45-inch top diameter, a 0.90-inch base diameter, and a height of 0.20 inches. Spacing is set at 2.35 inches on center with a 1.67-inch diagonal spacing.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
