A twenty-four-inch wide reverse pan concrete curb and gutter assembly bears on compacted select fill. The curb stands twelve inches high with a six-inch top width and features three-quarter-inch corner radii. The gutter section maintains a six-inch thickness at the outer edge and indicates the bottom of a contraction joint placed typically. The installation follows American Public Works Association standards plan number two hundred five.
6” R=3/4” | O . RA 1 CO SELECT FILL (TYP.) 24” BOTTOM OF CONTRACTION JOINT (TYP.) INSTALLED PER APWA STANDARDS NOTE: CURB AND GUTTER TO BE INSTALLED PER APWA STANDARDS PLAN NO. 205 00
