The connection and transition between proposed and existing asphalt pavement sections is formed by a saw cut of two inches minimum depth made in the existing asphalt pavement, with the existing material and base course removed to accommodate the new pavement layers. A tack coat is applied to the interface between the hot mix asphalt and existing surfaces to ensure proper bonding. The assembly is founded on a base course and a twelve-inch compacted subgrade below.
EXISTING UNDERLYING MATERIAL 24" 24" REMOVE EXISTING MATERIAL EXISTING ASPHALT PAVEMENT PROPOSED ASPHALT PAVEMENT BASE COURSE (GCA) EDGE OF EXISTING ASPHALT PAVEMENT, DIMENSION, OR LOCATION OF SAWCUT INDICATED ON PLANS 12" COMPACTED SUBGRADE (SEE NOTE 1) HOTMIX ASPHALT TACK COAT EXISTING BASE COURSE ACTUAL SAW CUT FULL DEPTH AND TACK COAT SAWCUT 2" MIN DEPTH
