Fiber roll sediment control installation details for slope and flat areas showing a trench depth of twelve inches minimum, with four inches maximum exposed height of the roll. The fiber roll is secured with three-quarter-inch by three-quarter-inch wood stakes spaced at a maximum of four inches. Adjacent rolls must tightly abut each other to prevent runoff from flowing under or around the assembly.
