The six-inch-wide concrete curb features a typical seventy-five-hundredths-inch radius corner at the top and stands four to six inches above the adjacent sidewalk per municipal standards. A sidewalk slopes away from the curb with an expansion joint positioned between the two concrete elements above a drainage notch. The notch measures four inches maximum in width and includes a typical profile set one inch below the interface. All dimensions and configurations conform to standard municipal public works requirements.
