C-4XRWS — Detail-Mech. Yard Wall At Exterior Wall

Civil · C-4XRWS

Detail-Mech. Yard Wall At Exterior Wall

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: C5
Discipline: Civil

Materials

Brick Cold-formed Steel Masonry / CMU Steel

Elements

Facades / Cladding Insulation Walls Waterproofing / Flashing

Text on the drawing

2 3/8" CEMENT FIBER LAP SIDING SHEET WATER BARRIER 7/8" HAT CHANNEL AT 12" O.C. DOUBLED AT CORNER EXTERIOR ACOUSTIC WALL PANEL EXTERIOR ACOUSTIC WALL PANEL 8" CMU WALL. RE: STRUCTURAL BRICK VENEER. BRICK VENEER. 8" CMU WALL. RE: STRUCTURAL
