The drawing shows a reinforcing steel rebar bent into a 135-degree standard hook specifically designated for stirrups and ties of size #5 and smaller. Key geometric dimensions include a bend diameter referenced as 'D' and an extension length measuring at least 6 bar diameters (6db) or a minimum of 2 1/2 inches. This configuration ensures proper anchorage and development length within reinforced concrete structural elements.
Text on the drawing
135° D D 2 1/2" MIN 6db STANDARD HOOKS FOR TIES AND STIRRUPS #5 AND SMALLER
