An integral concrete curb and sidewalk assembly features a four-inch thick sidewalk transitioning into a six-inch high curb adjacent to the roadway. A contraction joint is positioned in the top surface near the curb face. The curb profile includes a one-inch radius edge and dimensions that vary from six inches to zero inches when transitioning to a flush curb.
6" 1" 5-1/2" 8" 4" 1" 6-1/2" FACE OF CURB ROADWAY 6-1/2" CONTRACTION JOINT 12" 1" (IN) R. INTEGRAL CURB SIDEWALK PER PLAN VARIES FROM 6" TO 0 WHEN TRANSITION TO FLUSH CURB FOR JOINT LAYOUT FOR ROADWAY/ PARKIN
