Eight five-eighths-inch steel gussets tapered to one-half-inch connect the circular structural elements. Two stainless steel hex-head bolts secure the assembly at the connection points along the interior ring. Two surface picks provide lifting or handling points for the assembly.
(2) STAINLESS STEEL HEX-HEAD BOLTS 8 - GUSSETS 5/8" TAPERED TO 1/2" 2 SURFACE PICKS
